Chapter 5: Positioning, Z-Index & Stacking Contexts

The real reason your tooltip is behind the modal and how to debug layout layering

Every front-end developer has tried this at least once:

z-index: 99999;

…and then wondered why it still doesn’t work.

alt text

The truth is: z-index by itself is meaningless unless you understand what a stacking context is and how the browser builds visual layers.

This chapter will walk you through all of it.

Section 5.1: The 5 Position Values And What They Actually Do

static (default)

relative

.parent {
  position: relative;
}
.child {
  position: absolute;
  top: 0;
  left: 0;
}

Now .child is anchored to .parent, not the page.

absolute

If no such ancestor exists → the reference is the <html> element.

fixed

Used for:

sticky

Section 5.2: What Is Z-Index?

z-index controls which element sits on top when they overlap.

Higher z-index = closer to the user

But: z-index only applies if the element is positioned.

.modal {
  position: fixed;
  z-index: 10;
}

No position, no z-index.

Section 5.3: The Stacking Context, What Nobody Taught You

A stacking context is like an isolated z-index world.

Inside a stacking context:

New stacking context is created by:

Example:

.parent {
  position: relative;
  z-index: 0;
}

.child {
  position: absolute;
  z-index: 9999;
}

If .parent is in a lower stacking context, .child cannot escape it.

Even if .child has z-index: 999999999, it will still render behind a sibling .modal with its own stacking context and z-index: 10.

Section 5.4: How the Browser Builds the Stack

  1. Start with the root stacking context (<html>)
  2. Look for any element that creates a new stacking context
  3. Inside each context, z-index defines order
  4. Higher contexts render over lower ones regardless of child z-index

Section 5.5: Debugging Stacking Contexts in DevTools

alt text

Chrome DevTools can help:

  1. Inspect an element
  2. Go to Computed → z-index
  3. Look at Stacking Context
  4. Use the Layers panel to see visual layers

Tip: Enable “Show stacking contexts” in DevTools experiments

You’ll see purple outlines around elements creating new stacking contexts.

Section 5.6: Common Stacking Bugs (And Real Fixes)

Tooltip hidden under image

.tooltip {
  position: absolute;
  z-index: 1000;
}

But .container has:

.container {
  opacity: 0.99;
}

Boom new stacking context. Tooltip can’t escape.

Fix: remove opacity or raise parent context’s z-index

.backdrop { z-index: 999; }
.modal { z-index: 1000; }

But .modal is inside a relative parent with z-index: 1.

Fix: raise parent’s z-index or move .modal outside the constrained context.

Section 5.7: Practical Strategies for Layering

Group your layers:

Layer z-index range
Base UI 0–10
Dropdowns 100–500
Modals 1000–1500
Toasts 2000+

Use utility variables or CSS layers:

:root {
  --z-modal: 1000;
  --z-dropdown: 500;
}

.modal {
  z-index: var(--z-modal);
}

Section 5.8: Isolation and GPU Promotion

Sometimes you need to isolate an element fully:

.container {
  isolation: isolate;
}

This cuts off the stacking flow and prevents accidental interference.

Also:

Summary: Z-Index & Position

Learn More

Coming Up Next

In Chapter 6, we’ll compare Flexbox, Grid, and normal layout flow and give you a real strategy for choosing the right tool for the job.
